Stainless Steel Vertical Mounted Magnetic Level Gauge Floated Water Level Controller with OEM Customization Support

Name: Stainless Steel Vertical Mounted Magnetic Level Gauge Floated Water Level Controller with OEM Customization Support
Brand: NUOYING
Price: 129 USD

Cheap Stainless Steel Vertical Mounted Magnetic Level Gauge Floated Water Level Controller with OEM Customization Support wholesale

Brand Name : NUOYING

Model Number : NYCFQ-UK

Certification : CE, SIL, ATEX

Place of Origin : Xi'an,Shaanxi,China

MOQ : 1pcs

Price : $129 to $259/pcs

Payment Terms : T/T

Supply Ability : 1000pcs per month

Delivery Time : 5-7 working day

Packaging Details : 40*30*30cm

Grade : Industrial

Warranty : 12 months

Customized support : OEM, ODM

Applications : Liquid, corrosive liquid

Probe material : 304, PTFE,316 (optional)

Power supply : 24VDC

Process temperature : -40 ~ +130℃

Process pressure : -0.1~2.0MPa

Signal output : 4~20 mA,0~1000Hz,RS485 Modbus RTU

Max. Centre to Centre Distance : 50~5000mm

Contact Now

New Arrival High Quality Float Type Diesel Fuel Tank Magnetic Flap Level Gauge Magnetic Level Meter

NYCFQ-UK Magnetic Float Level Meter

Product Parameters

Stainless Steel Vertical Mounted Magnetic Level Gauge Floated Water Level Controller with OEM Customization Support

Typical application	Liquid, corrosive liquid
Probe material	304, PTFE, PP (optional)
Power supply	24VDC
Operation temperature	-40 ~ +130℃
Medium density	500~2000kg/m³
Working pressure	-0.1~2.0MPa
Signal output	4-20mA
Process connection	Thread, flange (optional)

Products Description

NYCFQ-UK Magnetic Float Level Meter Working Principle

The magnetic float level meter works based on the principle of buoyancy and magnetic coupling, with a set of reed tubes and precision resistors inside the detection tube, when the magnetic float moves up and down along the detection tube with the change of liquid level.The dry tube located at the liquid level in the detection tube is turned on in turn so that the output electric positive value of the detection tube changes, and the conversion circuit module in the junction box converts the resistance value into 4~20mA current output.

NYCFQ-UK Magnetic Float Level Meter Design Feature

1. Simple structure, sturdy and reliable, stable operation.
2. The display indicates the liquid level in red, which is intuitive, eye-catching and easy to read.
3. Various installation forms and connection forms can be selected.
4. Large measuring range, no blind area in the whole process of measurement.
5. Continuous measurement of various liquids as well as high temperature, high pressure, corrosive and flammable and explosive medium levels.
6. The display is completely isolated from the measured medium, safe and reliable.
7. For special pressure and temperature can be professionally designed.

Stainless Steel Vertical Mounted Magnetic Level Gauge Floated Water Level Controller with OEM Customization Support Images
